Autonics : PA10-V, Sensor Controllers

Specifications

TypeHigh Function Controller

Width38 mm

Height76 mm

Length82 mm

Power Supply100 - 240 VAC 50/60 Hz

Allowable Voltage Range90 ~ 110% of power supply

Power Consumption100 VAC 50/60 Hz : Approx. 7 VA (Condition : 12 VDC/200 mA), 240 VAC 50/60 Hz : Approx. 10 VA

Power For External Sensor12 VDC ±10 % max. 200 mA

Input (IN1) (IN2)Selectable NORM/INV.

Operation for IN1. IN2 AND.

Input TypeNPN

Input Method[No voltage input] Impedance at short-circuit: Max. 300Ω. Residual voltage at short-circuit Max. 2V. Impedance at open-Min. 100 kΩ

Contact OutputOUT [250 VAC 3 A (Resistive load)]

Solid-State OutputNPN open collector output Max. 30 VDC 200 mA

O•C OUT

Response TimeRelay contact : Approx. 10 ms. Transistor output : 50 µs (When it is encoder mode)

Mechanical Relay Life CycleMin. 10000000 times

Electrical Relay Life CycleMin. 100100 times (250 VAC 3 A resistive load)
